Segmented Esophageal Stents

Segmented Esophageal Stents

Indication:

Malignant esophageal tumors in esophageal middle segment, distal

segment and some cases on the upper segment

Performance Characteristics:

■ Segmented modular stent body allowing independent movements between each module to maximize conformance to curved to tortuous anatomy

■ Segmented design minimizes migration

■ Comparably mild radial force and low axial force

■ Elastic covering to resist tumor inner growth

■ Variety of lengths and diameters

■ Extraction threads for removal and repositioning

■ Delivery system with markers for better position accuracy

Specifications:

REF	Middle/Ends Dia.  (mm)	Length  (mm)	Product illustration	Repositioning	Introducer System
					Push type	Knot type
Fully covered
GS-1-03-16085	16/18	85		Yes	24Fr*700mm	18Fr*650mm
GS-1-03-18085	18/20	85		Yes	24Fr*700mm	18Fr*650mm
GS-1-03-20085	20/22	85		Yes	24Fr*700mm	18Fr*650mm
GS-1-03-16120	16/18	120		No	24Fr*700mm	18Fr*650mm
GS-1-03-18120	18/20	120		No	24Fr*700mm	18Fr*650mm
GS-1-03-20120	20/22	120		No	24Fr*700mm	18Fr*650mm
GS-1-03-16150	16/18	150		No	24Fr*700mm	18Fr*650mm
GS-1-03-18150	18/20	150		No	24Fr*700mm	18Fr*650mm
GS-1-03-20150	20/22	150		No	24Fr*700mm	18Fr*650mm

Note：Exact lengths are decided by the quantity of segments.
